Detailed alternating yield check stresses over the circumference (Output Table)

Data description/Result options:

ANGLE:

Location at circumference where calculations have been performed

(measured in positive sense around x-axis from y-axis)

SIGI1-2:

Absolute value of principal stress difference σ1 - σ2 at inner wall location indicated by ANGLE

SIGI2-3:

Absolute value of principal stress difference σ2 - σ3  at inner wall location indicated by ANGLE

SIGI3-1:

Absolute value of principal stress difference σ3 - σ1  at inner wall location indicated by ANGLE

SIGO1-2:

Absolute value of principal stress difference σ1 - σ2 at outer wall location indicated by ANGLE

SIGO2-3:

Absolute value of principal stress difference σ2 - σ3  at outer wall location indicated by ANGLE

SIGO3-1:

Absolute value of principal stress difference σ3 - σ1  at outer wall location indicated by ANGLE





The number of rows is 48 (each 7.5°).

---
